2025 - 2026 Toyota C-HR+ Fuse Relay Boxes Location
2025 - 2026 Toyota C-HR +, has 2 fuse and relay boxes, 1 fuse relay box in the engine compartment and 1 fuse relay box in the passenger compartment.
Engine Compartment Fuse Relay Box Location:
The location of the fuse box in the engine compartment is on the driver's side of the engine. The fuse and relays layout diagram is on the fuse relay box cover. If you want a detailed layout, you can find it in the owner's manual.
Passenger Compartment Fuse Relay Box Location:
The location of the fuse box in the passenger compartment is on the driver's side under the dashboard, to the left of the steering wheel (LHD). The location of the fuse box in the passenger compartment is on the driver's side under the dashboard, to the right of the steering wheel (RHD). The fuse layout diagram is on the fuse box cover. If you want a detailed layout, you can find it in the owner's manual.
